Product identification

• Hidraoil Part number: GFX105049
• Brand of product: Berarma
• Part number: 01 PLP 05-16 FHRM
• Other numbers: 01PLP05-16FHRM 01PLP0516FHRM

Description

• Hydraulic variable displacement vane pump with mechanical regulator.
  Nominal displacement: 16 cm3/rev.
  Flow @ 1450 rpm: 23.2 liters/minute.
  Max working Pressure: 120 bar.
  Speed range: from 800 up to 1800 rpm.
  Pressure setting range: From 20 up to 120 bar.
  Rotation: Clockwise rotation (looking at the shaft end of the pump).
  Shaft type: Parallel diameter 20 mm.
  Flange type: Tipo ISO; centraje from diámetro 80 mm.
  Inlet port: 3/4" GAS.
  Outlet port: 1/2" GAS.
  Drain port: 3/8" GAS.
  Campo from regulación from cilindrada máxima: Permite regular la cilindrada máxima up to un valor mínimo from 3.1c/rev.
  Max pressure allowed in drain port: 1 bar.
