Product identification

• Hidraoil Part number: GFX102661
• Brand of product: Char-Lynn Eaton
• Part number: 104-3699-006
• Other numbers: 104-3699-004 104-3699-005 1043699004 1043699005 1043699006 charlin charlyn charlynn M02240AJ42AG0200010000000BCAAF

Description

• Hydraulic orbital motor for High Torque applications. for low speed and high torque applications.
  Shaft type: Parallel diameter 35 mm con chaveta from ancho 10 mm
  Flange type: Tipo magneto from 4 taladros con centraje from diámetro 82.5 mm.
  Displacement: 395 cm3/rev.
  Side Ports: Threaded G1/2 ports (1/2" BSPP)
  Drain Port: G1/4 Threaded Port (1/4" BSPP)
  Max speed: 191 rpm (intermittent operation: 287 rpm).
  Max. Torque: 775 Nm (intermittent operation: 925 Nm).
  Max. Pressure Drop: 155 bar (intermittent operation: 170 bar; peak load:205 bar).
  Max oil flow: 75 liters/minute (intermittent operation: 115 liters/minute).
  Opciones: -.
