Product identification

• Hidraoil Part number: GFX101338
• Brand of product: Sauer Danfoss
• Part number: 151-0402 OMR 100
• Other numbers: 1510402 OMR100

Description

• Hydraulic orbital motor for high torque applications. Geroller type.
  Shaft type: Parallel 25.4 mm diameter with 6.4 mm key width.
  Flange type: SAE-A Type 2 holes A2 Flange with 82.5 mm centering diameter and 106.4 mm distance between holes..
  Gearwheel set case width (L1): 17,4 mm.
  Displacement: 99,8 cm3/rev.
  Side Ports: G1/2 Threaded Ports (1/2" BSPP)
  Drain Port: Without Drain port.
  Max speed: 600 rpm (intermittent operation: 750 rpm).
  Max. Torque: 240 Nm (intermittent operation: 280 Nm; peak load:320 Nm).
  Max. Output Power: 13 kW (intermittent operation: 15 kW).
  Max. Pressure Drop: 175 bar (intermittent operation: 200 bar; peak load:225 bar).
  Max oil flow: 60 liters/minute (intermittent operation: 75 liters/minute).
  Max. starting pressure with unloaded shaft: 10 bar.
  Min. starting torque at max. press. drop cont.: 200 Nm.
  Min. starting torque at max. press. drop int.: 230 Nm.
  Intermittent operation: the permissible values may occur for max. 10% of every minute.
  Peak load: the permissible values may occur for max. 1% of every minute.
